Description
Printer
| Printer Type | 4-Colour 24″ (610 mm) |
| Number of Nozzles | 4,352 nozzles (BK 1,280 nozzles, C,M,Y: 1,024 nozzles each) |
| Maximum Print Resolution | 2,400 × 1,200 dpi |
| Nozzle Pitch | 1,200 dpi (2 lines) |
| Line Accuracy*1 | ± 0.1% or less |
| Ink Capacity | Sales Ink: 70 ml (BK, C, M, Y) Bundled Starter Ink: 70 ml (BK, C, M, Y) |
| Ink Type | Pigment Ink |
| Printer Language | SG Raster (Swift Graphic Raster)
PDF JPEG*2 |
| Printing Solutions | Canon PRINT Inkjet/SELPHY (iOS/Android), Canon Print Service (Android), Free Layout plus, PosterArtist, Direct Print Plus, PIXUS/PIXMA Cloud Link, Apple AirPrint, Mopria, ChromeOS |
| Management Solutions | Media Configuration Tool, Quick Utility Toolbox, Wi-Fi Connection Assistant, Printer Update Utility |
| Standard Interfaces (Built-in) | USB A Port USB Memory (Direct Print) PDF*3 / JPEG (Exif ver2.2/2.21/2.3)USB B Port (Series B, 4 pins) Hi-Speed USB Full Speed (12 Mbit/sec) High Speed (480 Mbit/sec) Bulk TransferIEEE 802.3 10base-T IEEE 802.3u 100base-TX SNMP, HTTP, TCP/IP (IPv4/IPv6)Wireless LAN: IEEE802.11b/g/n WPA-PSK (TKIP/AES） WPA2-PSK (TKIP/AES） WPA3-SAE (AES) WPA-EAP (AES)*4 WPA2-EAP (AES)*4 WPA3-EAP (AES)*4 |
| Standard Memory | 1 GB |
Print Speed*5
| Plain Paper (CAD Drawing) | 32 sec (Draft) (Monochrome) |
Scanner
| Scanner Type | Flatbed (CIS Scanner) |
| Optical Resolution (dpi)*6 | 1,200 x 2,400 dpi |
| Greyscale | 16 bit / 8 bit |
| Colour | RGB 16 bit / 8 bit |
| Greyscale / Monochrome | 1.5 ms/line (300 dpi) |
| Colour | 3.5 ms/line (300 dpi) |
| Maximum Document Size | A4/LTR (216 x 297 mm) |
Media Handling
| Media Feed and Output | |
| Roll Paper | One Roll, Top Load, Front Output |
| Cut Sheet | Top Load, Front Output*7 |
| Media Width (Roll / Cut Sheet) | Roll Width: 297 ~ 610 mm (A3 width to 24″); Cut Sheet Width: 210 ~ 297 mm (A3, A4, Letter) |
| Media Thickness (Roll / Cut Sheet) | 0.08 ～ 0.28 mm |
| Media Core Size | 2 inch core |
| Min. Printable Length | |
| Roll Paper | 203.2 mm |
| Cut Sheet | 203.2 mm |
| Max. Printable Length | |
| Roll Paper | 4 m*8 |
| Cut Sheet | 432 mm |
| Maximum Outer Roll Diameter | 110 mm or less |
| Borderless Printing Width | NA |
| Margins (Recommended Area) | |
| Roll Paper | Top/Bottom: 5 mm, Left/Right: 5 mm*9 |
| Cut Sheet | Top/Bottom: 5 mm, Left/Right: 5 mm*9 |
| Margins (Printable Area) | |
| Roll Paper | Top/Bottom: 5 mm, Left/Right: 5 mm*9 |
| Cut Sheet | Top/Bottom: 5 mm, Left/Right: 5 mm*9 |
Dimensions & Weight
| Dimensions (W x D x H) | |
| Main Unit | 968 × 545 × 395 mm (Auto Sheet Feeder Opened) 968 × 525 × 245 mm (Auto Sheet Feeder Closed) |
| Main Unit + Printer Stand + Basket (SD-24) | 968 × 870 × 874 mm (Basket Opened) 968 × 707 × 874 mm (Basket Closed) |
| Main Unit + Desktop Basket (BU-06) | 968 × 825 × 965*10 mm (Basket Opened) 968 × 525 × 965*10 mm (Basket Closed) |
| Weight*11 | |
| Main Unit | 33 kg |
| Main Unit + Printer Stand + Basket (SD-24) | 42 kg |
| Main Unit + Desktop Basket (BU-06) | 34 kg |
| Packaged Dimensions (W x D x H) | |
| Main Unit | 1120 x 726 x 406 mm |
| Stand + Basket (SD-24) | 1055 x 824 x 268 mm |
| Desktop Basket | 798 x 301 x 111 mm |
| Packaged Weight | |
| Main Unit | 45 kg |
| Stand + Basket (SD-24) | 16 kg |
| Desktop Basket | 1.8 kg |
Power & Operating Requirements
| Power Supply | AC 100 – 240 V, 50 – 60 Hz |
| Power Consumption | |
| Copy Operation*12 | 26 W or less |
| Sleep Mode*12 | 1.9 W or less |
| Power Off | 0.3 W or less |
| Operating Environment | |
| Temperature | 15 ～ 30°C |
| Humidity | 10 ～ 80% RH (no dew condensation) |
| Acoustic Sound | |
| Acoustic Power*13 | Operation: Approx. 6.0 Bels |
| Acoustic Pressure*13 | Operation: Approx. 41.5 dB (A) Standby: 35 dB (A) or less |
Accessories
| Printer Stand (Optional) | SD-24 |
| Desktop Basket | BU-06 |
Fitur Produk:
- Tipe Printer: 4-Warna 24″ (610 mm)
- Jumlah Nozzle: 4.352 (BK 1.280 nozel, C, M, Y: 1.024 nozel masing-masing)
- Resolusi Cetak Maksimal: 2.400 × 1.200 dpi
- Kapasitas Tinta: 70 ml (BK, C, M, Y)
- Jenis Tinta: Tinta Pigmen
- Bahasa Printer: SG Raster, PDF, JPEG
- Solusi Pencetakan: Canon PRINT Inkjet/SELPHY, Apple AirPrint, Mopria, ChromeOS
- Solusi Manajemen: Media Configuration Tool, Wi-Fi Connection Assistant
- Antarmuka Standar: USB A, USB B, Hi-Speed USB, Ethernet, Wireless LAN (IEEE802.11b/g/n)
- Memori Standar: 1 GB
- Kecepatan Cetak (Kertas Biasa CAD): 32 detik (Draft) (Monokrom)
- Tipe Scanner: Flatbed (CIS Scanner) dengan resolusi optik 1.200 x 2.400 dpi
- Ukuran Dokumen Maksimal: A4/LTR (216 x 297 mm)
